PMB212C 1pc Motor drive unit PPS

2 Phase bipolar microstep pulse motor driver
High output of 1.2A/phase RMS
Cost-effective, ultra-compact, ultra-light
Highest reliability due to simple design
EC directive conformity
Enforcement corresponding to RoHS compliance
Power supply DC10 to 27V, 1.5A Max
Driving method : Unipolar chopper constant current
Out put current : 0.2A to 1.0A/Phase
Excitation method : Microstep 1/1 to 1/60 division
Max response clock frequency : 500kpps
Net weight : 100g
Operating temperature : 0 to 40℃
Storage temperature : -10 to +80℃
RoHS compliant
